- Function : Cooling,
- BTU/hr : 18000,
- Rated Voltage : 230V ~ 50Hz,
- Rated Input Power (W) : Version 1008:1570,
- Version 1013: 1565,
- Rated Current (A) : Version 1008: 6.82
/Version 1013: 6.95
- Cooling Capacity (W) : 5275
- EER : Version 1008: 3.35
/Version 1013: 3.37
Basic Features Cooling Features :
Compressor Type Rotary (Inverter)
Refrigerant Type R-32
Refrigerant Amount (Kg) Version 1008: 0.92kg
Version 1013: 0.65kg
Operating Range (Ambient Temperature) 20˚C to 52˚C
Evaporator Fin Type
Louvered Fin
Condenser Type
Copper Tube Condenser
Condenser Fin Type
Slit Fin
Maximum Pipe Length
10m
Basic Features Cooling Features Operations Remote & Air Deflection :
Display Type
LCD
Operation/Control Via IR (Infrared Ray)
Child Lock Yes
Temperature Unit Change Yes (16°C to 31°C)
Auto UP-Down Swing Yes
Auto Left-Right Swing Yes
Dimensions & Weights :
Indoor Dimensions (mm) [L×W×H] Unit: 933 x 321 x 230
Packing: 1010 x 380 x 290
Outdoor Dimensions (mm) [L×W×H] Unit: 844 x 310 x 546
Packing: 900 x 372 x 610
Net Weight (Indoor) (Kg) 12.5 ± 0.5
Gross Weight (Indoor) (Kg) 15 ± 0.5
Net Weight (Outdoor) (Kg) Version 1008: 27.5 ± 1
Version 1013: 27 ± 1
Gross Weight (Outdoor) (Kg) Version 1008: 32 ± 1
Version 1013: 31.5 ± 1
Warranty Information
Warranty
Product Replacement Guarantee: 1 Year (Note: if there are manufacturing faults in the heat exchanger & compressor) #For Residential Usage : Compressor Guarantee: 10 Years, Spare Parts Support: 3 Years, After Sales Service: 1 Year (Free) #For Commercial Usage : Compressor Guarantee: 5 Years, Spare Parts Support: 2 Years, After Sales Service: 1 Year (Free)
Description
Split AC Air Conditioner
- Air Conditioner Type : Intelligent Inverter,
- Function : Cooling,
- Cooling Capacity : 18000 BTU/Hr/
5275 Watts/
1.5 Ton,
- Compressor : Rotary (Inverter),
- Refrigerant : R-32
